Overhead Deflector Machines

GT11-OD

Benefits:

Eliminates machine room access limitations
Simple motor coupling and brake adjustments
Easy installation, adjustments and preventative maintenance
Flange mount motors dismount easily and simplify costly motor alignment
Accessories can be easily removed


Machine	Roping	Speed	Max. Capacity	Machine Weight
GT11-OD	1:1	100-500 fpm	3000 lbs	2900 lbs. w/ out motor
	2:1	50-250 fpm	6000 lbs.

GT31-OD

Benefits:

Easy installation, adjustments and preventative
maintenance
Flange mount motors dismount easily and simplify
costly motor alignment
Simple brake adjustments
Eliminates machine room access limitations
Removable deflector sheave upright assembly
Removable and adjustable column supports
Integrated rope gripper mounting options standard


Machine	Roping	Speed	Max. Capacity	Machine Weight
GT31-OD	1:1	100-500 fpm	4500 lbs	3251 lbs. w/ out motor
	2:1	50-250 fpm	9000 lbs.

Basement Set Traction Machines (O.D.)
